The Data Speak for Itself...
Click above for larger image
Click above for larger image
Corporate Office:
Sheetz, Inc.
5700 6th Ave
Altoona, PA 16602
Website(s): www.sheetz.com
Established in 1952 in Altoona, Pennsylvania, Sheetz, Inc. is one of America's fastest-growing family-owned and operated convenience store chains with more than 17,500 employees. The company operates over 550 store locations throughout Pennsylvania, West Virginia, Virginia, Maryland, Ohio and North Carolina. All Sheetz convenience stores are open 24 hours a day, 365 days a year.
Distributed By: Sheetz, Inc., Altoona, PA
Manufactured By: Pinnacle Oil Inc., Indianapolis, IN
Purchased at: Girard, OH
Date of purchase: 5/14/2017
Website(s): www.sheetz.com
The results of the tests conducted on this sample meet the SAE J300 specifications for the SAE Viscosity Grade listed on the product label, and are consistent with the listed API Service Categories.
|
Physical Properties |  |
||||||||
| Elemental Analysis | |
|||||||||
| Labeling | |
|||||||||
|
||||||||||
Note1: Although laboratory tests alone cannot be used to establish if engine oil meets an API Service Category, they can be used to determine if it doesn't. Note2: The specification for cold cranking viscosity includes only a maximum value; the minimum value shown in the “standard” area of the chart is truncated for illustrative purposes.
| PHYSICAL TESTS (click for test details) - a | Standard | Sheetz |
| TBN, mg KOH/g (ASTM D2896) | 8.35 | |
| Viscosity @ 100ºC, cSt (ASTM D445) | 6.9 to <9.3 | 8.75 |
| Viscosity @40ºC, cSt (ASTM D445) | 49.13 | |
| Viscosity Index (ASTM D2270) | 158 | |
| Viscosity @-30ºC mPa s (cP) (ASTM D5293) | 6,600 Max | 4,781 |
| Volatility, mass % loss, 1 hr, @ 250ºC (ASTM D5800) | 15 Max -c | 12.8 |
| ELEMENTAL ANALYSIS (click for test details) - a, b | ||
| Additives | ||
| Calcium, ppm | 2,450 | |
| Magnesium, ppm | 8 | |
| Phosphorus, ppm | 600 to 800 -d | 738 |
| Zinc, ppm | 838 | |
| Molybdenum, ppm | 44 | |
| Barium, ppm | <1 | |
| Boron, ppm | 2 | |
| Silicon, ppm | 6 | |
| Potassium, ppm | <5 | |
| Manganese, ppm | <1 | |
| Titanium, ppm | <1 | |
| Copper, ppm | <1 | |
| Sodium, ppm | <5 | |
| Vanadium, ppm | <1 | |
| Contaminants | ||
| Silver, ppm | <1 | |
| Aluminum, ppm | <1 | |
| Chromium, ppm | <1 | |
| Iron, ppm | <1 | |
| Nickel, ppm | <1 | |
| Lead, ppm | <1 | |
| Antimony, ppm | <1 | |
| Tin, ppm | <1 | |
|
||
